Sanitary Centrifugal Pumps YUY Series

Sanitary Centrifugal Pumps

Sanitary Centrifugal Pumps  YUY Series

Specially good for racing, turning without liquid, and vacuum air from tank.

Model No.: MSCP8806


Capacity: 1.5T~10T lift: 10M~60M

Material: AISI304, AISI316L

Gaskets: EPDM

Machanical seal(standard): C/SiC/EPDM

Standard: 3A/DIN/SMS/ISO etc.

Max. Temperature: 120C/248F.

Surface finishing: Inside & outside mirror Polish, or sand blasting outside, and Ra< 0.8.

Connection end: Clamp, weld, thread, union and flange.

Motor: ABB, 2900, 1450, 3600 min/1.5Hz, 60Hz


210V~230V/50Hz, 360V~400V/50Hz, 420V~460V/60Hz, 360V~400V/50Hz, 630V~690V/50Hz, 420V~460V/60Hz.

Min. Order: 1 PC

Transportation: BY SEA, BY AIR, BY COURIER

Position of Pump Shaft: Horizontal Pump

Influent Type of Impeller: Single Suction Pump

Impeller Number: Single-Stage Pump System




Download PDF catalogue (Sanitary Pump YUY Series)
